Trakkit Gemini – Wardrobe sliding system
Description
Delivery & Returns
Specification
The Gemini is a twin-track system that suits lightweight applications such as cupboards and wardrobes where a budget option is required.
The combination of the aluminium track with the ball bearing nylon wheels, guarantees a silent operation. The use of the adjustable 4-piece floor guide eliminates the need to make a groove under the door.
Kit Contents:
- Aluminium Top Hung Sliding Door Tracks (Available in 1.5 metre and 2.3 metre lengths)
- 2 x Four Wheeled Nylon Rollers
- 2 x Roller Bracket
- 2 x Bolt and Nut for connecting roller to bracket
- 2 x Track Stop Buffer
- 1 x Nylon Floor Guide
- 4 x Side-Fixing Brackets (1.5 metre kit)
- 6 x Side-Fixing Brackets (2.3 metre kit)
- 22 x Fixing Screws
Please Note: This wardrobe sliding door runners kit does not include doors
Features:
- 2000 mm Track
- Â 2 x Outward facing hangers
- 2 x Inward facing hangers
- 3 +1 Nylon bottom guides
- 1 x Door stop
- 30 x Fixing screws)
| Maximum door weight: 45kg |
| Minimum door thickness: 16mm |
| Maximum door thickness: 40 mm |
