Series 250 Sliding Door System – maximum weight capacity 1000kg

Runners Series 250 is used for heavy duty commercial applications, offering a smooth gliding system for both straight and folding configurations.

Series 250 maximum weight capacity is 1000kg.

Series 250 Sliding Door System - maximum weight capacity 1000kg

Series 250

Designed for heavy duty
commercial and agricultural
applications such as
warehousing, agricultural
buildings, hangars etc. The
comprehensive range of
hangers and components
offers a smooth gliding system
for both straight sliding and
folding configurations.

Series 250 straight sliding
systems are suitable for
timber or metal doors with a
maximum panel weight up
to 1000kg when using two
500kg 4 wheel hangers per
door. Capacity will be reduced
accordingly if using lower
capacity hangers from the
Series 250 range. Components
suitable for use with straight
sliding systems are detailed
below. Generally two hangers
are used on each door panel.
A third or fourth hanger can be
used to increase door weight
capacity. eg. using three
250-253 hangers would allow
a door panel weighing up to
1500kg to be used.

When using upper track
support brackets they should
be fixed at a minimum of
600mm and a maximum of
1000mm spacing. Series 250
upper track is NOT pre-drilled
and will require drilling for
soffit fixing whether installing
it with or without the use of
soffit fixing brackets.
